• Lọc Thủy Lực Hydac 1300R020V

Lọc Thủy Lực Hydac 1300R020V

  • Hãng sản xuất: HYDAC
  • Mã số: 1300R020V
  • Model máy:

Filter Media
The media that we offer in the Hydac 1300R020V is Sintered Stainless Steel and is ideal for hydraulic applications where fire resistant fluids are utilized, including EHC for power generation, Skydrol, jack-up/lift-up systems for turbine start up, governor control circuit for turbine speed and primary metal applications. EHC systems commonly use phosphate ester which can develop high TAN (total acid number) when exposed to water. The acid attacks the binding agent in Microgalss media. The result is lower efficiency and media migration, or fiber shedding, where the filter is generating contamination. Sintered steel filter media utilize sintered stainless steel fibers which are impervious to the acidic compounds that form in EHC systems.

Filter Seal
Due to Viton’s phenomenal chemical resistance, high temperature range and its low compression set, hydraulic filters with Viton O-rings are an excellent choice for anyone that cares about their operation.

Viton o-rings are recommended for:
  • Petroleum oils
  • Di-ester base lubricants (MIL-L-7808, MIL-L-6085)
  • Silicate ester base lubricants (MLO 8200, MLO 8515, OS-45)
  • Silicone fluids and greases
  • Halogenated hydrocarbons (carbon tetrachloride, trichloroethylene)
  • Selected phosphate ester fluids
  • Acids
  • Operating temperature -20°f to 250°f

A Word on Quality
At Hydrafil we insist on providing our customers with the highest quality of filtration products. As a result, all of our replacement elements are manufactured right here in the United States, under the most rigorous quality standards. Additionally, all of our filter elements carry six ISO Standards and we fully guarantee all of our products.

Filtration Efficiencyβ22[c] = 1000

Nominal Micron Rating25

Nominal Length18.9

Collapse Rating (psid)250

O-RingViton

Filter MediaSintered Stainless Steel 316L

Vui lòng liên hệ :

Kinh doanh HOÀNG XUÂN TAM (Mr)
Mobile 0919-243-248
Skype hoang.xuan.tam
Yahoo ht2709
Email sales@locthuyluc.com
Website http://locthuyluc.com/
